ATLANTIS – A240, A270, A300, A330 LITE
A240
7’10” long, 6HP max
A270
8’10” long, 10HP max
A300
9’10” long, 15HP max
A330
10’10” long, 20HP max
ATLANTIS-LITE tenders are created for customers who are looking for the perfect light-weight and roomy solution for their RIB needs.
The size range includes four models: A240, A270, A300 and A330.
These tenders come loaded with great features, including:
• Standard bow step panel – the perfect way to utilize space at the bow; use it as a step, a seat, or fuel tank pedestal.
• «GALA TABS» for quick, easy planing and a dry ride.
• Sliding seats installation system – the most convenient way to organize and customize the cockpit.
• Expertly equipped original GALA fittings provide an elegant, yet practical design.
Every boat is available with either VALMEX or HYPALON tubing in a variety of colours.
5 reasons to choose GALA
“GALA TABS” hull design
GALA Tabs are the feature created and patented by GALA. It significantly improve performance and let you get on plane as easy as no any other boat!
BOW STEP PANEL
There is a large step panel at the bow, so you can step on it, sit on it or attach the tank to it! Very convenient!
SLIDING ALUMINUM SEATS
Each model is equipped with a sliding aluminium seat with additional seat available.
EXTREMELY LOW WEIGHT
Each GALA Atlantis-LITE is extremely low weight. It makes them an unbeatable choice if you need something lite!
OVERPRESSURE VALVE
Each boat is equipped with the advanced Overpressure Valve for protection against overheating and over-inflating.
VIDEO
GALLERY
Features
STANDARD FEATURES:
- Medium-V, powder-coated aluminum hull with «GALA TABS» patented design, antiskid decking and hidden transom brackets
- ENVIROX chromate-free titanium hull protection
- Bow step panel with antiskid surface
- Rigid aluminum seat with sliding installation system
- Substantial keel protector
- 5 lifting eyes and 3 towing bow eyes
- Bow handle
- GALA bow cleat and 8/10 grab handles
- Soft curved 3-chamber VALMEX or HYPALON buoyancy tube with rounded bow and original «GALA-JET» design
- Overpressure valve
- Tough rubbing strake with splash guard
- One-way drain valve
- Two oars with oarlocks and oar stops
- High-efficiency foot pump
- Repair kit and manual
OPTIONAL EQUIPMENT:
- Overall cover
- Additional aluminum seat
- Removable soft cushion for aluminum seat
- Under-seat bag
- SEADECK double layer upgrade
- Tube protector upgrade
Specifications
|
Models |
A240 |
A270 |
A300 |
A330 |
|---|---|---|---|---|
| Length overall | 240 cm / 7’10” | 270 cm / 8’10” | 300 cm / 9’10” | 330 cm / 10’10” |
| Length inside | 170 cm / 5’7″ | 192 cm / 6’4″ | 222 cm / 7’3″ | 252 cm / 8’3″ |
| Width overall | 152 cm / 5’0″ | 152 cm / 5’0″ | 162 cm / 5’4″ | 162 cm / 5’4″ |
| Width inside | 76 cm / 2’6″ | 76 cm / 2’6″ | 78 cm / 2’7″ | 78 cm / 2’7″ |
| Tube Diameter | 38 cm / 15″ | 38 cm / 15″ | 42 cm / 17″ | 42 cm / 17” |
| Bare boat weight | 37 kg / 81 lbs | 41 kg / 90 lbs | 45 kg / 99 lbs | 50 kg / 110 lbs |
| Loading capacity | 300 kg / 660 lbs | 350 kg / 770 lbs | 400 kg / 880 lbs | 500 kg / 1100 lbs |
| Passenger capacity | 2 | 3 | 4 | 4 |
| Number of chambers | 3 | 3 | 3 | 3 |
| Engine recommended | 5 HP | 8 HP | 10 HP | 15 HP |
| Engine MAX | 6 HP | 10 HP | 15 HP | 20 HP |
| Engine weight MAX | 35 kg / 77 lbs | 50 kg / 110 lbs | 60 kg / 132 lbs | 80 kg / 176 lbs |
| Engine shaft length | 15″ (short) | 15″ (short) | 15″ (short) | 15″ (short) |
| Aluminum hull thickness | 2.5 mm / 7/64″ | 2.5 mm / 7/64″ | 2.5 mm / 7/64″ | 2.5 mm / 7/64″ |
| Boat design category | D | D | C | C |
All technical data are subject to change without notice. The products details and specifications may be changed from specified herein. All the dimensions are + or – 3%. All the weights are + or – 10%
Tube and decor colors
LIGHT GRAY / GRAY
Light gray tube
with gray decor.
White hull.
(Default color)
WHITE / GRAY
White tube
with gray decor.
White hull.
BLACK / GRAY
Black tube
with gray decor.
Dark gray hull.
CUSTOM COLOR
Some other colors for tube, tube decor and hull can be available on request. Check out availability with your Dealer.
